Features:

(1) The running speed is from fast to slow to reduce the impact of the machine. And the voice is low. It is not easy to damage the mould.

(2) Manual operation and auto operation for choice.

(3) Mould locking F=250 TONS

(4) The oil circuit is designed reasonable, which works quickly and steadily. The valves are adopted famous brand products.

(5) By using high and low pressure way; it can save the energy greatly.

1. Technical parameter

   1. Mold clamping force: 2.5MN

   2. Working pressure: 210KG/CM2

   3. Piston diameter: 400mm

   4. Upright space(hot plate area): 700X700mm

   5. Route: 550mm

   6. Lift height: 750mm

   7. Clamp speed: 110mm/s

   8. Return speed: 110mm/s

   9. Compression speed: ≥3mm/s

   10. Upright material: 45#

   11. Upright and piston: At least 100 micrometer chromeplate coating

   12. Upright and piston: 50 degree rockwell hardness

   13. Master cylinder: high grade ductile iron cast

   14. Motor: 7.5KW，Carter

   15. Power: 380V,50Hz

   16. Heating panel: 85mm，2x12=24kw, resist block

   17. Hydraulic component: magnetic valve: HUADE

   18. Oil pump: KCL

   19. PLC: Mitsubishi

   20. Machine weight: About 6700Kg

   21. Size: 2100X1300X2620mm
